Products

Product Description Engineering Drawings Specifications 3D Presentation
Product name:TE2.5mm Pitch Housing To TE2.5mm 12Pin To 03Pin Electronic Wire Harness
Part number:HC-WH2512CXXX02XX
Production Capacity500,000PCS can be produced every month at HECON
HECON Support the Trade TermsEXW / FOB Shenzhen / DAP etc.
HECON Support Payment methodsT/T, PayPal, Alibaba Pay, etc.
Delivery Time3-7 working days for making sample. 15 working days for production.
PackagingPE bag packing or Custom packing
ShippingBy sea, By air or by express delivery (DHL/UPS/FEDEX)
MOQWe support the MOQ from 50pcs to 100pcs.
CertificationUL, CQC, CE, ROHS, REACH, and SGS Testing reports.

Connector Type: 12Pin
Cable Type: UL2547 26AWG
Connector Material: PA6T
Cable Length: Customizable
Connector Color: White
Compliance: ISO 13485, ISO 9001 Certified, UL
Applications: Electronic communication, automotive electronics, medical beauty, industrial equipment, LED display, network IT, security, machinery and equipment, etc.
Country of Manufacture: China, Dongguan

FAQ

  • Q1: What is your MOQ?
    MOQ is 100pcs.
  • Q2: Can we get free samples?
    Yes, We can provide free 3-10pcs samples but freight collect and customized part you need pay samples cost.
  • Q3: What is samples lead time?
    Standard samples delivery date about 3-5 days and customized samples need about 7 -10 working days.
  • Q4: What is your mass production delivery date?
    2-3 weeks once confirm your order.
  • Q5: What is your advantages do you have?
    A. HECON is a professional manufacturer in custom wire harness cable assemblies and PCB connectors well customized parts design and solution with many years experience.
    B. Stability connectors and cable with high value.
    C. Support low MOQ100pcs and Fasting Shipping .
    D. All Products comply with ROHS and Reach Requirements.
    E. One-Stop-Source in China to save your cost and time.
    F. We HECON Products quality are guaranteed over 12 months.
  • Q6: Why choose HECON company?
    A. We HECON respect the customer terms to protect customer privacy projects.
    B. High Quality with attractive price .
    C. Fast Lead time, RTS delivery date 3-7days, Customized delivery date 10-15days.
    D. Happy deal & Honesty to customer and partner.
    E. Professional sales and reply your inquiries within 8 hours.
    F. HECON‘s Products and service are sold to more than 70 countries with good reputation.
  • Q7: How about your after -sales -service?
    A. Products can guaranteed 12 months once goods left our factory.
    B. We HECON deal with your complains within 8 hours.
    C. Honesty to customer and partner.
  • Q8: What is your HECON PCB Connector can be provide?
    Terminal Blocks, Board to Board, Pin Header , Female Header, Box Header, Ejector Header , IDC, Dip, Machined Pin Series , DIN41612, Micro Match, D-sub, Type-C, RJ11, IC sockets.  POGO PIN, POGO PIN Connectors, M Series Circular Connectors etc.
  • Q9: What is your advantage cables can be provide?
    Custom harness cable from 0.8mm to 6.35mm Housing.
    Molding Cables, Type C Cable, DB Cable, ECG Cable, Network Cable, USB Cable, FFC/ IDC Flat Cable with low MOQ and fast lead time.
  • Q10: What kind of payment does your company support?
    We have diversification of payment methods, TT, PayPal, Alipay.
Basic product attributes
Part number :HC-WH2512CXXX02XXConnector:Alternative、Original version
Specification:TE2.5mm Pitch Housing To TE2.5mm 12Pin To 03Pin Electronic Wire HarnessInsulation material:PVC, Rubber, Silicone, PE, Teflon
Cable length:500mm or customPacking method:Bag packing
Pin position:12P or customOEM & ODM Service:Yes
Sample time:3-7 daysSample:Support samples
Particulars
Specification CharacteristicsSpecific material electrical parameters
Pitch:TE2.5mmDC test:300v/ 10ms
Type:One by twoInsulation resistance:5.0M oHM/Min
Line specifications:CustomConductivity resistance:5.0 CHM/Max
Cable color:CustomSpecific material of rubber shell
Engineering Drawings:Support custom 2D, 3DHousing Shell:PA66、PA6T、PA46
Quality Control:100% electrical measurement, incoming inspection, product size inspection, 100% visual inspectionColor:White
Certificate:CE/ISO/RoHS, SGSOperating temperature range:-25 °c ~ 85 °c
