Product Description Engineering Drawings Specifications 3D Presentation

Electronic wire harness cable  are widely used in electronic communication, automotive electronics, medical beauty, industrial equipment, LED display, network IT, security, machinery and equipment, etc. Electronic connection lines are mainly used to carry signals and power connections between equipment. The wiring harness is a wiring component that connects various electrical equipment or automobiles in the circuit. It is composed of wiring terminals, rubber shells or connectors, wires, insulating sheaths and insulating wrapping materials.
In order to facilitate installation and maintenance, and to ensure that electrical equipment can work under harsh conditions, the wires of different specifications and different colors used in various electrical equipment or automotive electronics are combined into one through reasonable arrangements, and the wires are bundled with insulating materials. It is complete and reliable.
According to the different use environment of the wire harness, the corresponding wire specifications selected mainly include UL single-core wire, multi-core shielded wire, UL1007,UL1571,UL1061,UL1015 /26AWG/28AWG/30AWG/32AWG, etc. The main insulation materials include PVC, silica gel, PE, Teflon, etc., which usually have high temperature resistance, oil resistance, vibration resistance and friction resistance,
The materials of the rubber shell are mainly PA6,PA66,PBT, etc. According to the actual use, flame retardant or reinforced materials are added to the plastic to achieve the purpose of flame retardant or reinforced. The terminal materials are mainly divided into phosphor bronze and brass, and the coating, gold or tin plating can also be selected according to different needs.




Basic product attributes
Part number:HC-WH-2PXXXXXXX-01Connector:Original factory or Alternative
Specification:Terminal block to Y type terminal 2P wire harness cable assemblyInsulation material:PVC, Rubber, Silicone, PE, Teflon
Cable length:Size can be customized according to requirementsPacking method:Bag packing
Pin position:02PinOEM & ODM Service:Yes
Delivery time15-25 days after confirmation of orderSample:Support samples
